ERIE
CANAL - LOCK E 17 - LITTLE FALLS |
| Length |
300 feet |
| Width |
43.5 feet |
| Lift |
40.5 feet |
| Next EastBound Lock |
E 18 - 4.2 miles |
| Next WestBound Lock |
E 16 - 7.7 miles |
| Air Draft Restriction at Lock |
20' at Low side entrance |
| Aerial View of Lock E-17 |
 |
 |
Lock E 17 Low Side
Fixed Bridge 30A
Hor Clearance 90'
Vert Clearance 20'
|
|
Lock E 17 Low Side
|
 |
 |
Lock E 17 Low Side gate |
| Lock E 17 Inside |
 |
 |
Lock E 17 Sill
|
|
Lock 17 Inside
|
 |
 |
West of Lock 17
Low Side Gate
|
| Lock 17 Up |
 |
 |
Lock 17 Up |
| Lock 17 Upper Wall |
 |
