ERIE CANAL - LOCK O-5 - MINETTO
Length 300 feet
Width 43.5 feet
Lift 18 feet
NextNorthBound Lock O 6- 3.3 miles
Next WestBound Lock O 3- 6.45 miles
Air Draft Restriction at Lock none

Lock O 5 Approaching on the high side

Current sets to west if plant is making power

Starboard side LT

Lock O 5 High Side

Lock O 5 Dam



Lock O 5 entering from High Side
Lock O 5 sign
Inside Lock O 5

Lock O 5 Low Side
North of Lock O 5
