ERIE
CANAL - LOCK E 22 - NEW LONDON |
| Length |
300 feet |
| Width |
43.5 feet |
| Lift |
25.1 feet |
| Next EastBound Lock |
E 23- 28.65 miles |
| Next WestBound Lock |
E 21 - 1.35 miles |
| Air Draft Restriction at Lock |
none |
 |
Lock 22 Approach from High Side
|
|
Lock E 22 High Side
|
 |
 |
Lock E 22 Sign
|
| Lock 22 Sill |
 |
 |
Lock E 22 Leaving on the Low Side |
| Lock E 22 Exiting on the Low Side |
 |
 |
Shad West of Lock E 22 |
Bridge E 60
Hor Clearance 79'
Vert Clearance 24' |
 |
